BG RBSDLT Nexus Grid Brushed Steel 2 Way 150W Trailing Edge Dimmer Module
BG RBSDLT Nexus Grid Brushed Steel 2 Way 150W Trailing Edge Dimmer Module
Please Note:
We will supply whichever model (RBSDTR or RBSDLT) is available at the time of your order. Both models maintain the BG standards and features.
The BG Grid modular range allows you to build your own module configuration with a variety of combinations and finishes. This antique brass finish trailing & leading edge single dimmer module allows you to control your light levels and set the mood.
This dimmer has the ability to change from Trailing to Leading edge dimming (Default trailing). As technology has advanced to become more efficient and environmentally friendly, dimming has become more complicated. Trailing edge dimming is generally the suitable mode, especially for LED. If the connected lighting has compatibility issues it will result in flickering or poor dimming performance.
Load rating (min/max per module):
| Lamp Type | Trailing Edge | Leading Edge |
| Incandescent | 5-150W | 5-100W |
| Halogen (Eco + Std) | 5-150W | 5-100W |
| Dimmable LED | 5-150W | 5-100W |
- Soft start brings the lights to a set level in around 1 second and extends the life of lamps
- Smooth dimming control with silent operation - no noise when dimming
- Overload protection prevents failure if you mistakenly connect your dimmer to too many lights or transformers, and will turn the lights down or off until the load is corrected
- 2 way push on/off with rotary control
- Suitable for dimmable LED, Halogen and Incandescent lamps
- Support for lower wattage lamps eliminates flicker
- Captive backed out terminal screws for fast installation
- Module to be installed with grid frame and plate
- Max number of LED bulbs is 10
Please note that BG Grid items are only compatible with other BG grid components.
