This Part M grid panel combines an intelligent dual mode dimmer with a 20A 2 way switch on a single graphite front plate with white rockers.
Part M of the Building Regulations requires that switches can be seen and located easily by people with impaired vision, and contrast is how that is achieved. The graphite plate stands out against a light-coloured wall and the white rockers stand out against the plate. There is no visible plastic around the rockers and the screws are colour matched, so nothing interrupts the contrast. The front plate matches the power products across the Part M range.
Key Features & Specifications
Intelligent Dual Mode Dimmer Module
- Smooth & Silent: Provides smooth control of light levels with silent operation.
- Dual Mode: Switchable between trailing and leading edge, making it compatible with dimmable LED, halogen, and incandescent lamps.
- Soft Start: Brings lights to the set level in approximately one second, extending lamp life.
- Flicker Elimination: Supports lower wattage lamps to prevent flickering.
- Overload Protection: Automatically dims or shuts off lights if the load limit is exceeded to prevent failure.
- Control: 2-way push on/off operation with a rotary dial.
- Note: Please verify that your lamps are marked as dimmable.
20A 2-Way Single Pole Switch Module
- Versatile Control: Suitable for operating lights from two positions (e.g., staircases or hallways), or can be wired as a 1-way switch.
Installation & Mounting
- Grid Format: Modules locate and clip directly into the grid frame with captive backed-out terminal screws for fast installation.
- Back Box Requirement: Requires a standard UK back box with a minimum depth of 25mm.
Included Parts (Supplied by BG)
- RFR34: 2x 3 & 4 Gang Grid Yoke Frame
- RPM6: 1x 6 Module Part M Front Plate
- RDLT: 5x Intelligent Dual Mode Dimmer Module
- R12: 1x 20A 2 Way Single Pole Switch Module
