BG NPC22W Nexus Metal Polished Chrome 2 Gang 13A Switched Socket - White Insert
Nexus Metal Polished Chrome Double 13A Switched Socket - White Insert
About Product:
- Polished chrome double socket
- Top quality Polished Chrome finish - lightly lacquered to prevent finger marks
- Matching Polished Chrome rocker switches
- White plastic insert
- Specification: 13 amp, double pole (BS 1363 part 2)
- Requires a 25mm metal wall box
- Supplied with colour coded fixing screws
The BG Electrical Nexus Metal NPC22W is a polished chrome double (2 gang) switched electrical socket with white inserts, manufactured by British General Electrical.
Suitable for a huge range of locations around the home or the office, the NPC22W has a slimline design (only 31mm deep) with softly rounded corners for a sleek, modern effect wherever it's installed.
No plastic is visible around the matching polished chrome switches and the finish is also lightly lacquered to reduce the impression of fingerprints. These electrical sockets can easily be retrofitted into existing backboxes (25mm minimum box depth required), and are supplied with colour coded fixing screws and fitting instructions to ensure an easy installation.
Furthermore, the NPC22W is fitted with a moisture-control gasket which enables it to be installed into recently plastered walls without the risk of tarnishing the finish. Twin earths are fitted as standard to facilitate high-integrity protective connections, as per BS 7671 regulations.
As standard on all BG sockets and switches, the NPC22W comes with a 25-year guarantee for peace of mind.
| General Colour | Polished Chrome |
|---|---|
| Captive Terminal Screws | Yes |
| Backed-out Terminal Screws | Yes |
| Minimum Box Depth (mm) | 25 |
| Terminal Capacity (# x mm²) | 3 x 2.5, 3 x 4, 2 x 6.0 |
| Front Plate Insert Colour | White |
| Anti-fingerprint Lacquer | No |
| Anti-microbial Property | No |
| Fixing Screws Supplied | Yes |
| Number of Earth Terminals | 2 |
| Terminal Arrangement | Angled, Inline |
| Terminals with Colour Coding Print | Yes |
| Number of Sockets | 2 |
| Socket Type | G-3P UK Ireland Hong Kong 220-240V 13A |
| Number of Switches | 2 |
| Screw Caps | No |
| Switch Type (Ways & Poles) | Double Pole |
| Fixing Centres (mm) | W-120.6 |
| IP Rating | IP20 |
| Operating Voltage (V) | 220-240 |
| Warranty (years) | 25 |
